1-3mm Sheet Max 35mm Flange R2-R50 CNC Corner For | RFQ Sourcing Details
Laser Cutting Machines · Quote on request
This is a product procurement detail page: check specs, images, category context and related sourcing paths before sending an RFQ.
Product specs
Buyer's Digest
Use this page as a product-first sourcing checkpoint before sending an RFQ. Category: Laser Cutting Machines. Confirm application fit, capacity, materials, destination, lead time and compliance requirements before comparing suppliers.
Original product description
Product Features • Touch screen + PLC to control tool gap and working process. • Servo motor + ball screw control roller to square tool gap according to plate thickness • Each corner can be identify different inner radius according to thickness • Forming the R angle does not require open angle welding.
It only needs to pre-bend the two sides of the R angle by 90 degrees on the bending machine, and then roll and form the whole machine on this machine to automatically cut the excess edge material • The die types are divided into bending lower die, forming roller upper die and forming lower die.
The bending die is the same as the ordinary bending die, depending on the thickness of the plate. The upper die of the forming roller depends on the R angle that needs to be formed. The forming lower die is determined by the R angle of the upper die of the roller minus the thickness of the plate.
A lower die has four different R angles • The forming R angle is the same but the plate thickness is different.
It is not necessary to replace the forming roller upper die and forming lower die, only to adjust the gap between the forming roller upper die and the forming lower die Product Parameters Model CF-3050 Total Power 5.5KW Voltage 3. Phase 4. Wire 220V/380V Oil Pump Power 3.7KW 380V Air Pressure ≥0.8.
Mpa Processing Capacity Material Plate Thickness Flange Height Corner Radius Cold Rolled Steel Plate 0.6mm ≤10mm INSIDE:R2-R50 OUTSIDE:R0.8-R49 0.8mm ≤15mm 1.0mm ≤18mm 1.2mm ≤20mm 1.5mm ≤22mm 2.0mm ≤25mm 3.0mm ≤30mm Stainless Steel 0.8mm ≤10mm 1.0mm ≤15mm 1.5mm ≤22mm 2.0mm ≤27mm Aluminum Plate 0.8mm ≤15mm 1.0mm ≤18mm 1.0mm ≤22mm 2.0mm ≤25mm 2.5mm ≤27mm 3.0mm ≤30mm Weight 2600kg Workpiece Size Minimum 200*200mm Maximum 6000*6000mm
1-3mm | Applications and Buyer Notes
1-3mm is organized as a sourcing-ready Laser Cutting Machines reference. The page combines visible product or company data with structured procurement cues so buyers can compare application fit, specifications, quantity, quality requirements and lead-time ques
Applications
- Initial shortlist building for related product or supplier options.
- Specification and application fit review before bulk purchasing.
- Category, keyword and detail-page comparison before sending an RFQ.
Key specifications
- Category
- Laser Cutting BedsBased on visible page data; confirm exact value in the RFQ.
- Unit
- setBased on visible page data; confirm exact value in the RFQ.
- Model
- CF-3050 TotalBased on visible page data; confirm exact value in the RFQ.
- Power
- 3.7KW 380V Air Pressure ≥0.8Mpa Processing CapacityBased on visible page data; confirm exact value in the RFQ.
- Origin
- ChinaBased on visible page data; confirm exact value in the RFQ.
- Weight
- 2600kgBased on visible page data; confirm exact value in the RFQ.
- Voltage
- 380V/220V 3pBased on visible page data; confirm exact value in the RFQ.
- Material
- Stainless SteelBased on visible page data; confirm exact value in the RFQ.
Buyer tips
- State quantity range and split-delivery needs before price comparison.
- Add certification, material or inspection standards when they affect acceptance.
- For time-sensitive projects, include target arrival date and destination.
- For special applications, describe operating condition, installation environment and duty cycle.
FAQ
What should buyers confirm first?
Confirm application, specification, quantity, destination and lead-time requirements before comparing offers.
Can buyers inquire when specs are incomplete?
Yes. Add model, material, size, use case and inspection needs in the RFQ to make replies comparable.
How should this listing be evaluated?
Check title, category, specifications and related keywords against the actual sourcing requirement.
Source mix: ugc
Key specifications
Product sourcing keywords
These terms come from the title, visible copy and specifications, and link into matching aggregate pages.
Continue from this detail page into sourcing structure
These links connect the detail page back to category hubs, procurement aggregates and knowledge pages so new inventory is not isolated.
This URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 1 5g 6000 2500mm Full Protection Automatic Cnc Fiber Laser Cutting Tube Pipe MachineThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Procurement sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laser Cutting Machines categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laser Marking And Engraving categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laser Sources And Parts categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laser Welding And Cleaning categoryThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path CompanyThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Fiber Laser Cutter Suppliers sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Handheld Laser Welder Exporters sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path Laser Marking Machine Manufacturers sourcing pathThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 1 5kw 2kw 3kw Metal Stainless Steel Iron Aluminum Copper Cnc Fiber Laser Cutting Machine 1500 3000mmThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 1 5kw 3kw 3015 Single Table Fiber Laser Cutting Machine For MetalThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Internal sourcing path 1 5kw 3kw 6kw Fiber Table Laser Cutting Machine For Cs Ss Aluminum 5mm 12mm 15mmThis URL was refreshed but still has no Googlebot evidence, so it is promoted into shared internal links for crawl discovery.
Cover Exchanged Fiber Laser Metal Sheet Cutting MachineRequest Quote
Open Type Fiber Laser Sheet Cutting Machine - VS SeriesRequest Quote
